This 775 sq. ft. one-storey modular home offers a perfect blend of modern design, durability, and efficiency. Ideal as a primary residence, guest house, rental unit, or vacation retreat, it is built with high-quality materials and energy-efficient features for a hassle-free living solution. Quick to install and fully customizable, it’s designed to suit your needs.
PRICE $75.000 CAD
GALLERY
DETAILS
One-storey residential module with a total area of 775 sq.ft (including terrace 290 sq.ft)
FLOOR AREA
- Total 775 sq. ft
- Terrace 290 sq.ft
- Living room and kitchen 233 sq.ft
- Bedroom 132 sq.ft
- Washroom 55 sq.ft
- Hall 48 sq.ft
- Furnace room 18 sq.ft
AVAILABLE OPTIONS
- Kitchen
- Washroom
- Interior renovation
- Landscaping and Hardscaping
FRAME
Frame of the living module: made of CLT panels. Exterior and interior walls are 100 mm CLT wooden boards, sawn to size on CNC.
MATERIAL
Material: Pine ; Kiln-dried lamellas with a moisture content of 12-14. Cross-section of CLT panels -100 mm, L= up to 7500 mm depending on the needs of the Buyer;
The inner side is sanded, ready for finishing; antiseptic treatment of all structures.
Wood defects: roughness: the depth of unevenness is no more than 1 mm; mechanical damage: depth not more than 1 mm.
FRAME FASTENING
Frame fastening: Structural self-tapping screws for wood 8.0x180mm with a TORX 40 press washer (or equivalent).
WALLS
TechnoNICOL parainsulation or (analogue). Roof covering – Clickfold Grand Line 0.45 Drap ST with film on locks (or equivalent) RAL 7024 (wet asphalt) or equivalent.
FACADE
Front facade (part), Rear facade Planken (pine or spruce).
ROOF
TechnoNICOL parainsulation (or equivalent). Roof covering – Clickfold Grand Line 0.45 Drap ST with RAL 7024 lock film (wet asphalt) or equivalent.
GLAZING
Windows, door: Melke Evolution 70 Anthracite, Titan AF fittings, External color: Anthracite-grey , Inner colour: Anthracite-grey or analogue Filling: 4MF, Glazing bead: .Black,Glazing bead groove plug black frame Entrance door Melke Evolution 70 Anthracite Door fittings External color: Anthracite-grey (inside) Inner colour: Anthracite-grey (outside) Fillings: 4MF or equivalent.
TERRACE:
Terrace board (pine, spruce)
Lumber and fasteners included.
Assembly instructions.
FLOOR PLAN
